New Products

!

Fast-Fit Gel Type LC Connector

LC connectors for fast termination of loose single-mode optical fibre data cable. Fibres should have a cleaved or polished face and have their buffer/insulator layers trimmed to appropriate length. After careful cleaning the bare fibre is inserted into the connector where it's face meets with a tiny ball of gel which has a refractive index matched to the fibre and to the glass linkage within the connector. The connector has a small latch which clamps the fibre for a permanent fixing.

Specs:
Size: ~40mm x 6mm x 4mm
Insertion loss: 0.3dB (typical)

Sold as a pack of 10 Connectors



BY-A6S-Fusion-Splice

Two Week Special

The latest unit from Eloik.

 New Portable BY A6S for Optical Cable Fibre Fusion Splicer.

Brief Introduction.

  • Small in size.
  • Light in weight.
  • 7 seconds fast splicing, 9 seconds arc heating.
  • 300 to 360 times splicing and heating per battery charge.
  • 100% automatic fibre detection and splicing start.
  • Average splicing loss 0.02dB(SM) 0.01dB(MM) 0.04dB(DS) 0.04dB(NZDS).
  • PAS fibre core alignment technology.
  • CMOS image sensor imaging technology.
  • Carrying bag also your work platform.
  • Saves picture of splice with date for audit.
  • Large 5.25ins LCD Colour Screen.
  • Green or Blue carry case
  • Blue or Red Fusion Splicer main unit.



  • Standard Package.
  • Optical fibre fusion splicer.
  • Power Adapter.
  • AC power Lin
  • Electrodes.
  • Cooler Clip.
  • Stripper.
  • Miller Pincers.
  • Blowing Dust Ball with Brush .
  • Specification.
  • Fibre Cleaver.
  • Carrying case





1. Superior qualified standard polishing;

2. 100% optic test: Insertion Loss: ≤0.3 (PC); ≤0.2 (APC); ≤0.2 (UPC);

3. 100% optic test: Return Loss: ≥45 (PC); ≥60 (APC); ≥55 (UPC);

4. φ0.9mm, φ2.0mm, φ3.0mm cable optional;

5. Simplex and duplex connector available;

6. Good exchange ability and good durability;

7. Available in fibre bunch, ribbon fan-out, pigtail available;

8. Meets ISO9001, ROHS and Bell core GR 326-core standards;





Optical Fibre Range Tester with VFL

Overview

FOFR-101 Optical Fibre Ranger with VFL ) is used in the test and maintenance of fibre network and comes with a built-in visual fault locator function which can detect cable faults. It is a newly designed fibre optic tester and aims at fibre network installation, engineering acceptance and maintenance. It is the most lightweight, economical optical fibre barrier equipment, using OTDR principle, integrated powerful analysis software and can quickly and accurately detect the location and type of fibre optic cable failure point. Fibre test data up to 2,500 records can be stored and the screen can directly display the results.

Key Features

  • Integrated visual fault location function
  • Tests the length of the fibre, distance between two nodes of the fibre and determines the location of the fault point
  • Maximum detection distance of 37.28 mi (60 km)
  • One-touch fibre link fault location, detection and measurement
  • Automatic reflection event, attenuation event analysis
  • Automatic Pulse Width Control design to ensure a convenient operation.
  • Provides up to 2000 test record queries
  • Up to 2500 measurement results can be stored in the unit
  • Storage view function through the host computer for data viewing, storage and deletion
  • Display of curves and traces through software
  • Auto power-off time is 10 minutes

Additional Information

Panel and Function

Appearance





2u - 4u 19" Horizontal Mount Low Profile Wall Mount Cabinet

Space too tight for a full-sized cabinet or rack? Mount your switches, routers, and other equipment heads-up with our Low-Profile Secure Wall mount Cabinet.
The cabinet keeps your equipment secure.

-horizontal distribution cabinet featuring a low-profile design and has been engineered to mount patch panels, hubs, routers, switches within two mounting bays.

-Welded design for additional strength.

-Secure reversible lockable front door.

-1u cable access opening at Base can be fitted
with brush strip panel to keep dust out.

-1u opening at top for either additional height if required( 75.0mm)
for unit or can be fitted with vented panel for extra ventilation.

-2 sets of 2u 19" rails fitted internally

-Cable access to rear

Working depth internal : 250mm
O/all height : 400mm
O/all width : 500mm
O/all depth : 150mm

*Please Note* Image 1 shows enclosure fitted with the follow: This is for picture purposes only and does not come with Enclosure.*

1x 1u TP Link Switch, 1x 1u 24 Port Patch Panel, 1x 1u 4 Way PDU, 1x 1u vented slotted panel (to act as mini shelf or cable tie panel )

*Please Note* Image 2 shows enclosure fitted with the follow: 1x set of 5u adjustable rails. This is for picture purposes only and does not come with Enclosure.*











Fibre Optical Connector Square SC Bare Fibre Optic Adapter

Bare fibre adapter is a very efficient media to connect bare fibre to fibre optic device, it usually used in installation to test links. One side of the bare fibre adapter is the bare fibre, the other side is the fibre optic connector to plug into equipment.




Features:



Insertion Loss Typical: ≤0.2dB;

Return Loss: ≥50dB;

Exchangeable: ≤0.2dB;

Repeatability: ≤0.2dB;

Durability: >1000 times;

Operating Temperature: -40~+80C

Storage Temperature: -45~85C



Applications:

WANs,LANs,CATV

Testing equipment

Communication system

Telecommunication networks

Temporarily connect bare fibre

1x SC Bare Fibre Adapter

Two way unequal splitter (Tap)

FBT Coupler Tap / Splitters are widely accepted and used in passive optical networks, especially for instances where the split configuration is smaller (1×2, 1×4, etc.). FBT is the traditional technology in which two fibres are placed closely together, typically twisted around each other and fused together by applying heat while the assembly is being elongated and tapered. Satsearch supply high quality FBT splitters, single mode couplers with single/double/three windows with competitive price to make your optical network system cost effective. Wide bandwidth 1260um - 1590um

Use:- Tree and star distribution

Any of the Coupling Ratio can be ordered, we stock some of the ratio's but others will take 10-14 days to supply.



PoE Detector

A Must-have companion for any pro This pocket-size PoE Detector indicates the type of PoE ion a cable ising bright, easy-to-see LED display. Quickly and identify IEEE 802.3af/at, 24 volt passive, even reverse polarity Mode B.

Ergonomically designed Fits comfortably between two fingers while allowing for rapid cable testing RJ45 input, the PoE Detector is powered by PoW, so there's no need to worry about battery life.



WS-PoE-Tester

This PoE tester belongs in every tool kit - great for testing PoE camera, ip phones and wifi installations. Connect the source to your PoE switch or injector, connect the load to your Camera or Phone, wifi or other 802.3af/3at power device. The tester will display the power used, voltage available, and current flowing.

Diagnose PoE problems with this tool

See how much power any PoE or DC powered device actually needs

Measure available voltage at the remote end of a PoE connected device

Observe loss in Ethernet cable

Mode A display from 20v to 56 volts

Mode B display from 20v to 56 volts

DC input display from 5v to 56 volts

Measure PoE currents up to 500ma (28 watts)

Use the 2.1mm DC connectors to measure voltage and current / power in 24, 48 and 56 volt installations

DC current up to 5 amps

2.1mm to 2.1mm jumper included

Bright LED display - alternate between Voltage, Current and Power.

Foam Tape

Multi Buy

Can be used on textured surfaces. High-strength core maintains a thin, consistent bond line. Easy liner release. Perfect to use on LED strip mounting at indoor or outdoor (included bathroom)suitable for indoor or outdoor use. (including bathrooms), used to mount our Mini PLC Splitters.


Length: 3m
Width: 4 mm , 6 mm, 12 mm , 20 mm

Fibre Steel Tape Removal Tool

Ripley Miller /  Fibre Steel Tape Remover 1.0 - 3.0 mm

 Easily opens/separates the steel tape armour on fibre optic cable

Designed to remove armour from 3mm cable. Global Satellite.

• Unique counter rotation mechanism opens steel tape armour in 2 1/2 – 3 1/2 turns allowing for cutting of the armour

• Accommodates steel tape armour from 1–3 mm OD

• Neodymium rare earth magnet holds tool halves together making operation easy

• Tool totally heat treated for long life

• Screw clamps are high-strength alloy steel

• 1.5 in (38.1 mm) outside diameter fits comfortably in you hand

• Dimensions: Diameter 1.5 in (38.1 mm) x .82 in (20.7 mm)

• Weight: 9.0 oz (258 g)
